Before the advent of the mortar spraying machine, the plastering works were all carried out manually. If all were done manually, not only would there be many workers, but the construction efficiency would be slow. However, the emergence of mortar spraying machine has greatly changed the construction efficiency of plastering engineering. Mechanized construction not only reduces personnel consumption, but also saves time and money. So how to operate this mortar spraying machine? This article will give you a detailed summary of the operation steps of the mortar spraying machine:
Operation guide of mortar spraying machine
1. Before starting each shift, install a hand oil pump several times to inject oil into the transmission parts. Electric screw cement mortar spraying machine
2. After connecting the power supply, first electric main motor, check whether the purpose of the rubber screw torsion label is the same, if there is divergence, you should adjust the power phase line (this check is required every time you borrow the power from the beginning)
3. Connect the conveying hose and spray head, if the water is 5L to the hopper, start the motor to pump the clean water out, so that the hopper, pump body and conveying hose will shut down after pumping out most of the water.
4. Insert hand putty or paint into the hopper to start spraying (the air compressor should be started first and the air valve should be opened)
5. It is strictly forbidden to run idly in the hopper without material and water.
6. After the work is completed, drain the remaining material in the hopper, and put enough clean water into the hopper, clean the hopper, and start the pump out, clean the nozzle of the hose machine, know that the pump is full of clean water, so as to avoid the residual material in the hose This kind of solidification can block the hose and nozzle.
How To Operate Mortar Spraying Machine?
7. If the shutdown time is too long, wipe the machine clean, and write down the booster screw. After oiling, keep it properly and keep it installed from the beginning.
8. In the work, the pressure of the pump is insufficient, and the booster nail bolts can be adjusted or the booster rubber sleeve and booster worm can be replaced.
9. Before spraying, the sprayed area should be infiltrated with water; when spraying, the spray head should be as vertical as possible to the sprayed surface (the distance can be adjusted according to the spraying result), spray evenly in layers, and coordinate with the flattening process. If the wall surface is too dry or the time after spraying is too long, it will seriously affect the ending, and the process must be changed.
10. The material should be evenly charged into the material, without interruption, and the conveying screw twisting type is strictly prohibited. It is strictly forbidden to stir in the hopper with a stick to prevent injury.
11. Once the spray pipe is blocked, switch the switch to the manual position, only turn on the compressor, remove the quick connector in front of the pump head, then plug the spray head downwards, the wind pressure will produce the reflected pressure, and the pipe will be left with slurry Blow out, after installing the quick connector, start to work normally.
12. When operating the spray archer, wear a helmet, protective glasses, protective clothing and other protective equipment.
13. The supercharged rubber sleeve and supercharged screw are damaged parts. For the delayed operating life, during the initial operation, the supercharged nail screw is more loose. When the pressure is reduced, the flow rate is reduced significantly. The compression bolt is adjusted so that It is in normal working condition.
Through this article, do you know how to operate the mortar spraying machine correctly? If you want to know more about the professional problems of mortar spraying machine, please feel free to leave a message with us online! !
