The mortar spraying machine basically has no floor dust, saves water and materials, can greatly reduce the cost, and is simple to operate, and can be used for indoor and outdoor wall spraying. Cement mortar grouting, bridge grouting and waterproof surface spraying, fire protection spraying, thermal insulation material spraying, ceiling spraying, wall spraying, paint spraying, garden spraying, relief effect coating.
Product Features of Mortar Spraying Machine
1. Multi-purpose for one machine, can spray ordinary mortar, thermal insulation mortar, dry powder mortar, anti-cracking mortar, interface agent, putty, construction glue, adhesive, fireproof material, epoxy paint, etc. (the material must be well mixed in advance).
2. This machine is an electric screw type high-pressure mortar spraying machine. It has advanced technology, simple operation and maintenance, and can be operated proficiently without special training. 3. The operation is simple and can be used for indoor and outdoor wall spraying.
3. The spraying equipment has large flow rate and high pressure, which overcomes the above defects. The density of the mortar far exceeds the national standard, avoiding the troubles caused by problems such as quality, construction period, and price.
Operation Of Mortar Spraying Machine For Wall Cement
Operation of wall cement mortar spraying machine
1. Before starting each shift, press the hand pump several times to inject oil into the transmission parts.
2. After connecting the power supply, first electric main motor, check whether the direction of rotation of the rubber spiral is consistent, if it is inconsistent, it is necessary to change the phase line of the power supply (this check must be performed every time the power supply is reconnected)
3. Connect the conveying hose and spray head, add 5L of clean water to the hopper, start the motor to pump the clean water to wet the hopper, the pump body and the conveying hose, and shut down after pumping most of the water
4. Add putty or paint into the hopper to start spraying (the air compressor should be started and the air valve should be opened first)
5. It is strictly forbidden to run idly in the hopper without material and water.
6. After the work is completed, the remaining material in the hopper must be drained, and enough fresh water should be injected into the hopper, the hopper should be cleaned, and the pump should be turned on to clean the hose and the spray head until all the water is pumped out, so as to avoid the remaining material Solidify and block the hose and nozzle.
7. If the shutdown time is too long, wipe the machine clean, remove the booster screw, apply oil, store it, and reinstall it when using it.
8. If there is insufficient pumping pressure during the work, you can adjust the booster stator bolts or replace the booster rubber sleeve and booster worm.
9. Before spraying, the sprayed area should be penetrated with water; when spraying, the spray head should be perpendicular to the sprayed surface (the distance can be adjusted according to the spraying effect) as much as possible, and spray uniformly and coordinate with the flattening process. If the wall surface is too dry or the spraying time is too long, it will seriously affect the leveling effect, and the process must be changed.
10. The material should be evenly charged into the hopper without interruption. When the conveying screw rotates, it is strictly prohibited to stir in the hopper with sticks to prevent injury.
11. Once the spraying pipe is blocked, switch the switch to the manual position, only turn on the compressor, remove the quick connector on the front of the pump head, and then plug the spray head downwards, the wind pressure generates reverse pressure, and the slurry in the conveying pipe is left. Blow out, after installing the quick connector, start to work normally.
12. During the operation of the spray hand, you should wear a hard hat, protective glasses, protective clothing and other protective equipment.
13. The booster rubber sleeve and booster screw are wearing parts. In order to prolong the service life, the booster stator bolt is more loose when it is used for the first time. When the pressure is reduced and the flow rate is significantly reduced, adjust the compression bolt to make it In normal working condition.
